Cutting & Trimming
The five-section bone sawing machine can cut a single bone into five sections, and the cutting size can be customized. It features continuous operation and can be connected to upstream and downstream processing equipment. It is suitable for industries such as prefabricated food and meat products.
Specifications
| Name | 5-section bone sawing machine |
| Voltage | 380V |
| Motor Power | 3.5kw |
| Machine Weight | 370KG |
Machine Size | 1020*820*1800mm |
| Cutting Width | 30-60mm (support customization) |
| Workbench Dimensions | Width 300mm |
| Maximum Cutting Height | 160mm |
| Saw Blade Linear Velocity | 20m/s |
| Saw Blade Length | 1985mm*2; 3355mm*2 |
Description
Features of the bone cutting machine:
● Sturdy and durable material: The entire frame structure, as well as the main body and outer shell, are all made of thickened stainless steel plates and sealed.
● Comprehensive safety protection: Equipped with stainless steel protective covers to safeguard all moving parts, ensuring the safety of operators.
● Convenient conveying design: The conveying part is separately arranged and installed with slide rails and positioning pins. It can be separated from the main body, making it easy to remove for cleaning and eliminating sanitary dead ends.
● Efficient and stable cutting: Adopting a structure with multiple sets of saw wheels and multiple feeding belts for synchronous material conveying, enabling multiple cuts in one operation, improving efficiency, and ensuring cutting safety and product stability.
● Intelligent motor control: The main motor is controlled by a frequency converter, and the saw wheels start slowly, ensuring the stable operation of the machine and extending the service life of the saw blades.
How to operate the bone cutter:
Put the bones on the conveyor belt one by one. Turn on the switch. The cutting device starts to cut the bones continuously.
Bone Cutting effect:
● It can achieve continuous feeding and sawing.
● It can make 5 cuts at a time.
● The cut is flat, with few chips and low loss.
● The cutting size can be customized, and the customization range is within 30-60mm.
